As a leading industrial supply partner and bearing distributor across Uttar Pradesh, Manglam Sales Corporation provides genuine NBC 22209 CC W33 spherical roller bearings to manufacturing plants, heavy machinery OEMs, and maintenance workshops. The NBC 22209 CC W33 features a cylindrical bore, high-strength pressed steel window-type cages (CC), and an outer ring circumferential lubrication groove with three re-lubrication holes (W33) to ensure continuous, low-friction performance under heavy dynamic radial loads and bi-directional axial thrust. Designed by National Engineering Industries (NEI) to accommodate heavy shock loads and structural misalignments, this bearing delivers maximum reliability across demanding operational environments. Partnering with Manglam Sales Corporation guarantees authentic NBC product sourcing, bulk stock availability, and swift dispatch to major industrial belts across Uttar Pradesh—including Kanpur, Noida, Ghaziabad, Lucknow, Agra, and Varanasi.
Standard Dimensions & Technical Specifications
Parameter Specification
Bore Diameter 45 mm
Outer Diameter 85 mm
Width 23 mm
Basic Dynamic Load Rating 82.6 kN
Basic Static Load Rating 91.3 kN
Bore Type Cylindrical (Straight Bore)
Cage Design (CC) Two-piece stamped steel window-type cage with floating guide ring
Lubrication Feature (W33) Outer ring lubrication groove with 3 oil holes
Misalignment Capability Self-aligning design up to ~1.5° to 2.5°
Key Technical Advantages
Self-Aligning Construction: The spherical raceway design in the outer ring allows automatic adjustment for shaft flexure, housing distortion, or initial mounting angular misalignments without inducing high edge stresses.
High Load Capacity (CC Cage): Stamped steel window-type cages house two rows of symmetrical barrel rollers, enabling maximum roller packing density to handle continuous heavy radial loads and impact shocks.
Efficient Lubrication Distribution (W33): Built-in oil holes and a central groove on the outer ring deliver lubricant directly into the raceway contact zones, reducing heat buildup and extending service life.
Standard Dimensions & Technical Specifications
Parameter Specification
Bore Diameter 45 mm
Outer Diameter 85 mm
Width 23 mm
Basic Dynamic Load Rating 82.6 kN
Basic Static Load Rating 91.3 kN
Bore Type Cylindrical (Straight Bore)
Cage Design (CC) Two-piece stamped steel window-type cage with floating guide ring
Lubrication Feature (W33) Outer ring lubrication groove with 3 oil holes
Misalignment Capability Self-aligning design up to ~1.5° to 2.5°
Key Technical Advantages
Self-Aligning Construction: The spherical raceway design in the outer ring allows automatic adjustment for shaft flexure, housing distortion, or initial mounting angular misalignments without inducing high edge stresses.
High Load Capacity (CC Cage): Stamped steel window-type cages house two rows of symmetrical barrel rollers, enabling maximum roller packing density to handle continuous heavy radial loads and impact shocks.
Efficient Lubrication Distribution (W33): Built-in oil holes and a central groove on the outer ring deliver lubricant directly into the raceway contact zones, reducing heat buildup and extending service life.
